Description
| Lowrance HDS-16 Live | AI 3-In-1 | No XD |
| Display | 7″ Diagonal | 7″ Diagonal |
| Resolution | 1024×600 | 1024×600 |
| Interface | Full-Touch | Full-Touch |
| Dimensions | 9.21″x5.73″x3.0″ | 9.21″x5.73″x3.0″ |
| Transducer | ActiveImaging 3-in-1 | No |
| Ethernet | Yes | Yes |
| Card Slot | Yes (1 Micro SD) | Yes (1 Micro SD) |
| WiFi | Yes | Yes |
| Bluetooth | Yes | Yes |
| NMEA | Yes | Yes |
-Active Imaging 3-in-1 Transducer required (select models)
-New Active Imaging 3-in-1 – CHIRP/SideScan/DownScan – (select models)
-Active Imaging 2-in-1 ready (No transducer model)
-LiveSight real-time sonar compatible (Transducer required)
-Smartphone notifications
-C-MAP Genesis Live onscreen mapping
-StructureScan 3D with Active Imaging enhancements
-High-performance quad-core processor
-FishReveal Smart Target View
-Full high-definition HDS SolarMAX HD multi-touch screen with the widest range of viewing angles – viewable even through polarized sunglasses
-Preloaded high-detail C-MAP US Enhanced charts with 1-foot contours on 4,000-plus lakes
-C-MAP Easy Routing, Navionics Autorouting capability
-Dual-Channel CHIRP – dual sonar-range coverage from the same transducer
-Live Network Sonar – cover more water and mark fish targets more clearly from a network of CHIRP sonar transducers
-Wireless and Bluetooth connectivity
-Heat Map feature allows anglers to see trends in water temperature changes to quickly target key fishing areas
-Enhanced Surface Clarity lets you see more fish targets near the surface
-Quick Access Control Bar provides one–touch access to system controls
-Built-in CHIRP and Broadband Sounder
-SmartSteer control for Xi5 Trolling Motor and Outboard Pilot
-Radar and SonicHub2 audio server connectivity
-NMEA 2000 engine support
